JDD-SSCW silent braided wrap is woven by polyester monofilament and polyester multifilament. The special structure offers excellent reduction of noise. The side-entry design makes it easy to install, remove and reuse for wire harnesses or cables, especially where it is installed in difficult areas to reach such as door panels or dashboards.
Application:
Most commonly be used on wires harnesses and cable assemblies providing a tough, durable protection and noisy reduction in the automotive, railway, industrial machinery fields.
Technical data:
Material: PET monofilament and multifilament
Working temperature: -50℃~+150℃
Melting point: 240±10℃
Flammability: VW-1
Color: Black
Cerrtificate: RoHS, Halogen free
Cutting cool: Hot knife
| Part No. | I.D.(d) | Overlapping(%) | Max. bundle dia. | Packing (L) |
| SSCW-005 | 5mm | 25% | 6mm | 200m/spool |
| SSCW-009 | 9mm | 10mm | 100m/spool | |
| SSCW-013 | 13mm | 14mm | 50m/spool | |
| SSCW-019 | 19mm | 20mm | 25m/spool | |
| SSCW-025 | 25mm | 26mm | 25m/spool | |
| SSCW-032 | 32mm | 33mm | 25m/spool |
Notes:
1.The part No.will be followed by BK,GR and so on to indicate the color of tube.
2.Special packages, sizes and colors can be supplied upon request.
3.All numerical data shows average or typical values, not including customized sizes.
