Kevlar® fiber is a material with excellent thermal stability and outstanding tensile strength , the Kevlar® fiber is 20 times stronger than the steel wire in same diameter. Kevlar® braided sleeving is using this fiber yarn. Furthermore it offers good chemical resistance, heat-resistance and has no melting point.
Application:
It offers outstanding abrasion resistance for cables and hoses in aerospace and other high-tech applications.
●Material: Kevlar® fiber
●Working temperature: -170℃～+250℃
●Melting point: non melt
●Color: Yellow
●Cutting tool: Scissors
Dimensions:
| Part No. | Nominal Size | Expandable range | Packing |
| ( W ) | ( I to O ) | ( L ) | |
| KL-003 | 3mm | 1mm---4mm | 500m/spool |
| KL-006 | 6 mm | 5mm---8mm | 500 m/spool |
| KL-008 | 8 mm | 6mm---10mm | 350 m/spool |
| KL-010 | 10 mm | 7mm---13mm | 350 m/spool |
| KL-012 | 12 mm | 8mm---16mm | 300 m/spool |
| KL-015 | 15 mm | 10mm---20mm | 250 m/spool |
| KL-020 | 20 mm | 14mm---26mm | 200 m/spool |
| KL-025 | 25 mm | 18mm---33mm | 200 m/spool |
| KL-030 | 30 mm | 20mm---39mm | 150 m/spool |
| KL-040 | 40 mm | 30mm---52mm | 100 m/spool |
| KL-050 | 50 mm | 40mm---65mm | 50 m/spool |
Note:
1. Nominal size indicates the flat width. I.D indicates the round inner diameter.
2. Special package, sizes and colours can be supplied upon request.
3. All numerical data shows average or typical value, not including customized sizes.
4. Kevlar is a trademark of Dupont.
