Polyester textile sleeve is woven from polyester multifilament. With the particularly smooth inner wall, it could reduce the frictional resistance problems, provides easy installation. The tight woven construction helps dispense the flow of fluid in a ruptured hose.
Application:
It is widely used to protect hydraulic pipes, rubber hose, plastic pipes, wire harness from damage, this kind of sleeve can also be used in industrial and construction fields where outstanding hose productions are needed.
Technical data:
●Material: Polyester
●Working temperature: -50℃~+150℃
●Melting point: 240±10℃
●Color: Black
●Approval: RoHS, MSHA, ISO 6945
●Cutting tool: Scissor and hot knife
| Part No. | flat width（W） | I.D. | Wall thickness（T） | Packing (L) |
| NSSP-027 | 27 | 17 | 1.0 | 50m/roll |
| NSSP-031 | 31 | 20 | 1.0 | |
| NSSP-036 | 36 | 23 | 1.0 | |
| NSSP-039 | 39 | 25 | 1.0 | |
| NSSP-042 | 42 | 27 | 1.0 | |
| NSSP-049 | 49 | 31 | 1.0 | |
| NSSP-052 | 52 | 33 | 1.0 | |
| NSSP-054 | 54 | 36 | 1.0 | |
| NSSP-063 | 63 | 40 | 1.0 | |
| NSSP-069 | 69 | 44 | 1.0 | |
| NSSP-074 | 74 | 47 | 1.0 | |
| NSSP-083 | 83 | 53 | 1.0 | |
| NSSP-086 | 86 | 55 | 1.0 | |
| NSSP-094 | 94 | 60 | 1.0 | |
| NSSP-104 | 104 | 66 | 1.0 | |
| NSSP-115 | 115 | 73 | 1.0 | |
| NSSP-146 | 146 | 93 | 1.0 | |
| NSSP-176 | 176 | 112 | 1.0 |
nit:mm
