Auto FR1130 expandable sleeving is made of larger Nylon 6.6 and smaller polyester monofilament mixed braiding, the dual monofilament construction offers durable abrasion resistance and oil resistance in a wide range of industrial applications. It is lightweight and the expandable structure allows for easy to install over long lengths.
Application:
It’s used to cover cables, wire harnesses, tubes, industrial hoses where need extremely anti-abrasion in automotive, railway and panel board field.
Technical data:
●Material: Polyester, Nylon
●Working temperature: -50℃~+150℃
●Flammability: FMVSS302
●Color: Black
●Approval: RoHS
●Cutting tool: Hot knife
Dimensions:
| Part No. | Nominal Size (W) | Expanded Range | Packing (m/spool) | ||
| Inch | mm | min.(I) | max.(O) | ||
| FR1130-010 | 3/8" | 10 | 7 | 15 | 350m |
| FR1130-012 | 1/2" | 12 | 8 | 17 | 300m |
| FR1130-014 | 5/9" | 14 | 9 | 20 | 250m |
| FR1130-016 | 5/8" | 16 | 10 | 23 | 250m |
| FR1130-019 | 3/4" | 19 | 13 | 28 | 200m |
| FR1130-025 | 1" | 25 | 16 | 35 | 200m |
| FR1130-032 | 1-1/4" | 32 | 20 | 45 | 100m |
Unit: mm
Notes:
1. Nominal size indicates the flat width.
2. This sleeving has expandable character, the following sizes are covered by the nearest:
16mm=15mm, 19mm =20mm , 32mm =30mm , 38mm=40mm, 51mm=50mm.
3. Customized size, special package, cut into different length can be supplied upon request.
4. All the numerical data are average or typical values, not including customized sizes.
